Chapter 7 – Telnet Dialout

Multi-Tech Systems, Inc. MultiConnect Serial-to-Serial Adapter User Guide (S000354A)

66

Optional Configuration Commands

(Return to Scenario 1 - Setup Manual Dialout

Notes:

)

(Return to Scenario 2 - Auto Dialout

Prerequisites

)

(Return to Scenario 3 - Auto Dial-out in RAW-Mode

Notes:

)

The following commands can be used for optional configurations:

Enable/Disable the Authentication for Dial-out session

# set login auto-dialout-login

Enable/Disable the Switching-between-Dialout & Command Prompt feature

# set ip telnet escape-monitor

Set the Escape-Monitor-String to switch between Dialout and Command Prompt sessions.

# set ip telnet escape-string "+++inet"

Enable/Disable the RAW mode globally for all Dial-out sessions.

# set ip telnet raw-mode

Enable/Disable the RAW mode for the serial port S0.

# set serial s0 raw-dialout

Set the Baud rate for the serial port S0 to be taken for a Dialout session.

# set serial s0 baud-rate

Set the Flow control for the serial port S0 to be taken for a Dialout session.

# set serial s0 flow-control

Set the Parity for the serial port S0 to be taken for a Dialout session.

# set serial s0 parity

Set the Data bits for the serial port S0 to be taken for a Dialout session.

# set serial s0 data-bits <7/8>

Set the Stop bits for the serial port S0 to be taken for a Dialout session.

# set serial s0 stop-bits <1/1.5/2>

Set the Flow control for the serial port S1 to be taken for a PPP session

# set serial s1 flow-control

Set the Parity for the serial port S1 to be taken for a PPP session

# set serial s1 parity

Set the Data bits for the serial port S1 to be taken for a PPP session

# set serial s1 data-bits <7/8>

Set the Stop bits for the serial port S1 to be taken for a PPP session

# set serial s1 stop-bits <1/1.5/2>
