M A G N U M 6 K S W I T C H E S , M N S - 6 K U S E R G U I D E
11
ENABLE NONE
NONE
DISABLE
0 Not Configured
12
ENABLE NONE
NONE
DISABLE
0
Not Configured
13
ENABLE NONE
NONE
DISABLE
0 Not Configured
14
ENABLE NONE
NONE
DISABLE
0 Not Configured
15
ENABLE NONE
NONE
DISABLE
0 Not Configured
16
ENABLE NONE
NONE
DISABLE
0 Not Configured
Magnum6K25(port-security)##
F
IGURE
60 – Viewing port security settings on a switch. On port 9, learning is enabled. This port has 6
stations connected to it with the MAC addresses as shown. Other ports have learning disabled and the
MAC addresses are not configured on those ports
Magnum6K25(port-security)##
learn port=11 enable
Port Learning Enabled on selected port(s)
Magnum6K25(port-security)##
show port-security
PORT
STATE SIGNAL
ACTION LEARN COUNT MAC ADDRESS
--------
---------- -----------
----------- ---------- ---------- ----------------------
9
ENABLE LOG
NONE
ENABLE
6
00:e0:29:2a:f1:bd
00:01:03:e2:27:89
00:07:50:ef:31:40
00:e0:29:22:15:85
00:03:47:ca:ac:45
00:30:48:70:71:23
10
ENABLE NONE
NONE
DISABLE
0 Not Configured
11
ENABLE NONE
NONE
ENABLE
0 Not Configured
12
ENABLE NONE
NONE
DISABLE
0
Not Configured
13
ENABLE NONE
NONE
DISABLE
0 Not Configured
14
ENABLE NONE
NONE
DISABLE
0 Not Configured
15
ENABLE NONE
NONE
DISABLE
0 Not Configured
16
ENABLE NONE
NONE
DISABLE
0 Not Configured
Magnum6K25(port-security)##
F
IGURE
61 – Enabling learning on a port. Note – after the learning is enabled, the port security can be
queried to find the status of MAC addresses learnt. If there were machines connected to this port, the
MAC address would be shown on port 11 as they are shown on port 9
Magnum6K25(port-security)##
allow mac=00:c1:00:7f:ec:00 port=9,11,13
Specified MAC address(es) allowed on selected port(s)
Magnum6K25(port-security)##
show port-security port=9,11,13
PORT
STATE SIGNAL
ACTION LEARN COUNT MAC ADDRESS
--------
---------- -----------
----------- ---------- ---------- ----------------------
9
ENABLE LOG
NONE
ENABLE
6
00:e0:29:2a:f1:bd
00:01:03:e2:27:89
