M A G N U M 6 K S W I T C H E S , M N S - 6 K U S E R G U I D E
Tag based vlan Added Successfully.
Vlan id :20
Vlan name : sales
Ports :14-16
Magnum6K25(tag-vlan)##
add id=20 name=marketing port=14-16
ERROR: Duplicate Vlan Id
Magnum6K25(tag-vlan)##
add id=30 name=marketing port=14-16
Tag based vlan Added Successfully.
Vlan id :30
Vlan name : marketing
Ports :14-16
Magnum6K25(tag-vlan)##
show vlan
VLAN ID: 1
Name : Default VLAN
Status : Active
-----------------------------------------------------
PORT |
MODE | STATUS
-----------------------------------------------------
9
| UNTAGGED | UP
10 | UNTAGGED | DOWN
11 | UNTAGGED | DOWN
12 | UNTAGGED | DOWN
13 | UNTAGGED | UP
14 | UNTAGGED | DOWN
15 | UNTAGGED | DOWN
16 | UNTAGGED | DOWN
VLAN ID: 10
Name : engineering
Status : Pending
----------------------------------------------------
PORT |
MODE | STATUS
----------------------------------------------------
14
| UNTAGGED | DOWN
15 | UNTAGGED | DOWN
16 | UNTAGGED | DOWN
VLAN ID: 20
Name : sales
Status : Pending
----------------------------------------------------
PORT |
MODE | STATUS
----------------------------------------------------
Note – the VLANs are not started as yet. Adding the
VLAN does not start it by default.
Intentionally done to show the effect of adding a
duplicate VLAN.
