M A G N U M 6 K S W I T C H E S , M N S - 6 K U S E R G U I D E
153
: specifies the switch (bridge) priority value. Priority This value is used along with the
witch MAC address to determine which switch in the network is the root device. Lower
h ports
re the forwarding points. A higher cost means the link is “more expensive” to use and
port from participating in STP discovery. Its best to only
llow trunk ports to participate in STP. End stations need not participate in STP process.
tates and from learning to forwarding states. The value ranges from 4 to 30 seconds.
witch is the root device, this is the time between messages being
ansmitted. The value is from 1 to 10 seconds. Default value is 2 seconds
d by the switch
efore the switch discards the information and updates the address table again. Value
s
values mean higher priority. Value ranges from 0 to 65535. Default value is 32768
Cost: A path cost is assigned to individual ports for the switch to determine whic
a
falls in the passive mode compared to the link with a lower cost. Value ranges from 0 to
65535. Default value is 32768
Status: Enables or disables a
a
Forward-Delay: indicates the time duration the switch will wait from listening to learning
s
Default value is 15
Hello: When the s
tr
Age: This is the maximum time a message with STP information is allowe
b
ranges from 6 to 40 seconds with default value of 20 seconds
Magnum6K25(stp)##
show stp config
STP CONFIGURATION
-----------------
Spanning Tree Enabled(Global)
: NO
Spanning Tree Enabled(Ports) : YES, 9,10,11,12,13,14,15,16
Protocol : Normal STP
Bridge ID : 80:00:00:20:06:25:ed:80
Bridge Priority : 32768
Bridge Forward Delay : 15
Bridge Hello Time : 2
Bridge Max Age : 20
Root Port : 0
Root Path Cost : 0
Designated Root : 80 :00:00:20:06:25:ed:80
Designated Root Priority : 32 768
Root Bridge Forward Delay : 15
Root Bridge Hello Time : 2
Root Bridge Max Age : 20
RSTP CONFIGURATION
-----------------
Rapid STP/STP Enabled(Global) : NO
Magnum6K25(stp)##
show stp ports
