M A G N U M 6 K S W I T C H E S , M N S - 6 K U S E R G U I D E
Status: Enables or disables a port from participating in STP discovery. It’s best to only
allow trunk ports to participate in STP. End stations need not participate in STP process.
Forward-Delay: indicates the time duration the switch will wait from listening to learning
states and from learning to forwarding states. The value ranges from 4 to 30 seconds.
Default value is 15
Hello: When the switch is the root device, this is the time between messages being
transmitted. The value is from 1 to 10 seconds. Default value is 2 seconds
Age: This is the maximum time a message with STP information is allowed by the switch
before the switch discards the information and updates the address table again. Value
ranges from 6 to 160 seconds with default value of 20 seconds. Use a larger number when
there are a large number of nodes. Maximum number of nodes are 160.
Magnum6K25#
rstp
Magnum6K25(rstp)##
show rstp
RSTP CONFIGURATION
-----------------
Rapid STP/STP Enabled(Global) : NO
Magnum6K25(rstp)##
show active-stp
Current Active Mode: RSTP.
RSTP is Disabled.
Magnum6K25(rstp)##
rstp enable
Successfully set the RSTP status
Magnum6K25(rstp)##
show active-stp
Current Active Mode: RSTP.
RSTP is Enabled.
Magnum6K25(rstp)##
show rstp config
RSTP CONFIGURATION
-----------------
Rapid STP/STP Enabled(Global)
: YES
RSTP/STP Enabled Ports : 9,10,11,12,13,14,15,16
Protocol : Normal RSTP
Bridge ID : 00:00:00:20:06:25:ed:89
Bridge Priority : 0
Bridge Forward Delay : 15
Bridge Hello Time : 02
Bridge Max Age : 20
Check status of STP or RSTP. This command
shows STP or RSTP is disabled.
167
