M A G N U M 6 K S W I T C H E S , M N S - 6 K U S E R G U I D E
Version : Magnum 6K25 build 14.1 Jul 28 2008 07:51:45
MAC Address : 00:20:06:25:b7:e0
IP Address : 192.168.1.150
Subnet Mask : 255.255.255.0
Gateway Address : 192.168.1.10
CLI Mode : Manager
System Name : Magnum6K25
System Description : 25 Port Modular Ethernet Switch
System Contact : [email protected]
System Location : Fremont, CA
System ObjectId : 1.3.6.1.4.1.553.12.6
Magnum6K25#
show sysconfig
System Name
: Magnum6K25
System Contact : [email protected]
System Location : HO, Fremont, CA
Boot Mode : manual
Inactivity Timeout(min) : 10
Address Age Interval(min) : 300
Inbound Telnet Enabled : Yes
Web Agent Enabled : Yes
Time Zone : GMT-08hours:00minutes
Day Light Time Rule : USA
System UpTime : 36 Days 7 Hours 49 Mins 48 Secs
Magnum6K25#
F IGURE 6 -
Viewing the basic setup parameters. You can use ‘show setup’ or ‘show sysconfig’ to view
setup parameters
Some of the parameters in the Magnum 6K family of switches are shown above. The list
of parameters below indicates some of the key parameters on the switch and the
recommendations for changing them (or optionally keeping them the same).
Privilege levels
Two privilege levels are available - Manager and Operator. Operator is at privilege level
1 and the Manager is at privilege level 2 (the privilege increases with the levels). For
example, to set up a user for basic monitoring capabilities use lower number or operator
level privilege (Level 1)
The Manager level provides all Operator level privileges plus the ability to perform
system-level actions and configuration commands. To select this level, enter the ‘enable
’ command at the Operator level prompt and enter the Manager password,
when prompted.
Syntax enable
For example, switching from an Operator level to manager level, using the ‘enable’
29
