M A G N U M 6 K S W I T C H E S , M N S - 6 K U S E R G U I D E
16 TP(10/100) 128 2000000 Disabled 00:10
Magnum6K25(rstp)##
port port=9 status=enable
Magnum6K25(rstp)##
show rstp ports
RSTP Port Configuration
------------------------------------------------------------------------------------------------------------------
Port# Type Priority Path Cost State
Des. Bridge Des. Port
------------------------------------------------------------------------------------------------------------------
09 TP(10/100) 128 2000000 Forwarding 00:00:00:20:06:25:ed:89 00:09
10 TP(10/100) 128 2000000 Disabled
00:0a
11 TP(10/100) 128 2000000 Disabled 00:0b
12 TP(10/100) 128 2000000 Disabled 00:0c
13 TP(10/100) 100 250000 Forwarding 00:00:00:20:06:25:ed:89 00:0d
14 TP(10/100) 128 2000000 Disabled
00:0e
15 TP(10/100) 128 2000000 Disabled 00:0f
16 TP(10/100) 128 2000000 Disabled 00:10
Magnum6K25(rstp)##
timers forward-delay=20 hello=5 age=30
Successfully set the bridge time parameters
Magnum6K25(rstp)##
show rstp config
RSTP CONFIGURATION
-----------------
Rapid STP/STP Enabled(Global)
: YES
RSTP/STP Enabled Ports : 9,10,11,12,13,14,15,16
Protocol : Normal RSTP
Bridge ID : 00:00:00:20:06:25:ed:89
Bridge Priority : 0
Bridge Forward Delay : 20
Bridge Hello Time : 05
Bridge Max Age : 30
Root Port : 0
Root Path Cost : 0
Designated Root : 00:00:00:20:06:25:ed:89
Designated Root Priority : 0
Root Bridge Forward Delay : 20
Root Bridge Hello Time : 05
Root Bridge Max Age : 30
Topology Change count : 0
Time Since topology Chg : 567
Magnum6K25(rstp)##
exit
Magnum6K25#
F
IGURE
91 – Configuring RSTP on MNS-6K
