M A G N U M 6 K S W I T C H E S , M N S - 6 K U S E R G U I D E
152
STP CONFIGURATION
-----------------
Spanning Tree Enabled(Global) : YES
Spanning Tree Enabled(Ports) : YES, 9,10,11,12,13,14,15,16
Protocol
: Normal STP
Bridge ID : 80:00:00:20:06:25:ed:80
Bridge Priority : 32768
Bridge Forward Delay : 15
Bridge Hello Time : 2
Bridge Max Age : 20
Root Port : 0
Root Path Cost : 0
Designated Root : 80 :00:00:20:06:25:ed:80
Designated Root Priority : 32 768
Root Bridge Forward Delay : 15
Root Bridge Hello Time : 2
Root Bridge Max Age : 20
RSTP CONFIGURATION
-----------------
Rapid STP/STP Enabled(Global) : NO
Magnum6K25(stp)##
show stp ports
STP Port Configuration
--------------------------------------------------------------------------------------------------------------------------
Port# Type
Priority Path Cost State Des. Bridge Des. Port
--------------------------------------------------------------------------------------------------------------------------
09 TP(10/1
128 100 Forwarding 80:00:00:20: 80:09 00) 06:25:ed:80
10 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:0a
11 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:0b
12 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:0c
13 TP(10/100) 128 19 Forwarding 80:00:00:20:06:25:ed:80 80:0d
14 TP(10/100 128 100 Disabled 80:00:00:20:06:25:ed:80 80:0e
15 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:0f
16 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80 80:10
Magnum6K25(stp)##
F IGURE 85 – Enabling STP
ber|list|range>] value=<0-255 | 0-65535> - specifies the
port or switch level priority. When a port(s) are specified the priority is associated with ports and
Syntax c
pecified
P process. These ports typically would be end-stations. If you are not
Syntax t
es
Syntax priority [port=
their value is 0-255. If no ports are specified, then the switch (bridge) priority is specified and its
value is 0-65535
ost port= value=<0-65535> - cost is specific to a port and the
port(s) have to be s
Syntax port port= status= - specific ports may
not need to participate in ST
sure – let MNS-6K software make the decisions
imers forward-delay=<4-30> hello=<1-10> age=<6-160> - change the STP
Forward Delay, Hello timer and Aging timer valu
