M A G N U M 6 K S W I T C H E S , M N S - 6 K U S E R G U I D E
Root Bridge Max Age : 20
Topology Change count : 0
Time Since topology Chg : 100
Magnum6K25(rstp)##
forceversion rstp
Magnum6K25(rstp)##
show-forceversion
Force Version : Normal RSTP
Magnum6K25(rstp)##
show rstp config
RSTP CONFIGURATION
-----------------
Rapid STP/STP Enabled(Global)
: YES
RSTP/STP Enabled Ports : 9,10,11,12,13,14,15,16
Protocol : Normal RSTP
Bridge ID : 00:00:00:20:06:25:ed:89
Bridge Priority : 0
Bridge Forward Delay : 15
Bridge Hello Time : 02
Bridge Max Age : 20
Root Port : 0
Root Path Cost : 0
Designated Root : 00:00:00:20:06:25:ed:89
Designated Root Priority : 0
Root Bridge Forward Delay : 15
Root Bridge Hello Time : 02
Root Bridge Max Age : 20
Topology Change count : 0
Time Since topology Chg : 141
Magnum6K25(rstp)##
show-timers
Forward Delay Timer : 15 sec
Hello Timer
: 2 sec
Max Age : 20 sec
Magnum6K25(rstp)##
show rstp ports
RSTP Port Configuration
------------------------------------------------------------------------------------------------------------------
Port# Type Priority Path Cost State
Des. Bridge Des. Port
------------------------------------------------------------------------------------------------------------------
09 TP(10/100) 128 2000000 Forwarding 00:00:00:20:06:25:ed:89 00:09
10 TP(10/100) 128 2000000 Disabled
00:0a
11 TP(10/100) 128 2000000 Disabled 00:0b
12 TP(10/100) 128 2000000 Disabled 00:0c
13 TP(10/100) 128 200000 Forwarding 00:00:00:20:06:25:ed:89 00:0d
14 TP(10/100) 128 2000000 Disabled
00:0e
15 TP(10/100) 128 2000000 Disabled 00:0f
16 TP(10/100) 128 2000000 Disabled 00:10
Using forceversion the switch is now operating using RSTP.
Note the “show stp config” command also indicates the switch
protocol is RSTP.
