M A G N U M 6 K S W I T C H E S , M N S - 6 K U S E R G U I D E
• Same Duplex and
• LLL - enable
The necessary commands are
Syntax stp – STP Configuration mode
Syntax stp - Start (Enable) or stop (Disable) STP
Syntax set stp type= - set the spanning tree protocol to be IEEE 802.1d or 802.1w
(Spanning Tree Protocol or Rapid Spanning Tree Protocol)
Syntax show active-stp – Display which version of STP is currently active
Syntax show s-ring – show the status of S-Ring status and configuration
Syntax s-ring - enable or disable S-Ring capabilities
Syntax s-ring learn – start the learning process to discover the ring and the ports which make up the S-
Ring
Syntax s-ring add port= - define ports which make up the S-Ring ports. Note as
discussed earlier, you can create multiple S-Rings on a switch
Syntax s-ring del port= - remove the switch from S-Ring topology by eliminating the
end ports on the switch
Magnum6K25(stp)##
show s-ring
S-Ring Status:
sRing Status: DISABLED
Port 1 Port 2 Status
Magnum6K25(stp)##
s-ring enable
S-RING Enabled.
Magnum6K25(stp)##
show s-ring
S-Ring Status:
sRing Status: ENABLED
Port 1 Port 2 Status
Magnum6K25(stp)##
s-ring add port=1,7
