M A G N U M 6 K S W I T C H E S , M N S - 6 K U S E R G U I D E
-----------------------------------------------
PORT | MODE | STATUS
-----------------------------------------------
14 | UNTAGGED | DOWN
15 | UNTAGGED | DOWN
16 | UNTAGGED | DOWN
VLAN ID: 20
Name : sales
Status : Active
-----------------------------------------------
PORT | MODE | STATUS
-----------------------------------------------
14 | UNTAGGED | DOWN
15 | UNTAGGED | DOWN
16 | UNTAGGED | DOWN
VLAN ID: 30
Name : marketing
Status : Active
-----------------------------------------------
PORT | MODE | STATUS
-----------------------------------------------
14 | UNTAGGED | DOWN
15 | UNTAGGED | DOWN
16 | UNTAGGED | DOWN
Magnum6K25(tag-vlan)##
set-port port=14-16 tagging id=10 status=tagged
Port tagging enabled
Magnum6K25(tag-vlan)##
set-port port=14-16 tagging id=20 status=tagged
Port tagging enabled
Magnum6K25(tag-vlan)##
set-port port=14-16 tagging id=30 status=tagged
Port tagging enabled
Magnum6K25(tag-vlan)##
show vlan
VLAN ID: 1
Name : Default VLAN
Status : Active
-----------------------------------------------
PORT | MODE | STATUS
-----------------------------------------------
1 | UNTAGGED | UP
These commands sets the ports 14-16 as trunk ports. Note
VLAN 1 – the default VLAN is not tagged and will have to
be tagged to function as a trunk default VLAN. To filter out a
VLAN from the trunk – simply omit the VLAN from the set-
port command shown here.
