M A G N U M 6 K S W I T C H E S , M N S - 6 K U S E R G U I D E

154

STP Port Configuration
------------------------------------------------------------------------------------------------------------------------
Port#

Type

Priority Path Cost State

Des. Bridge Des. Port

------------------------------------------------------------------------------------------------------------------------
09 TP(10/

0) 128 100 Disabled 80:00:00:20:06:25:ed:80

80:09

10 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80

80:0a

11 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80

80:0b

12 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80

80:0c

13 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80

80:0d

14 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80

80:0e

15 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80

80:0f

16 TP(10/100) 128 100 Disabled 80:00:00:20:06:25:ed:80

80:10

Magnum6K25(stp)##

stp enable

Successfully set the STP status

Magnum6K25(stp)##

show stp config

STP CONFIGURATION
-----------------
Spanning Tree Enabled(Global)

: YES

Spanning Tree Enabled(Ports)

: YES, 9,10,11,12,13,14,15,16

Protocol

: Normal STP

Bridge ID

: 80:00:00:20:06:25:ed:80

Bridge Priority

: 32768

Bridge Forward Delay

: 15

Bridge Hello Time

: 2

Bridge Max Age

: 20

Root Port

: 0

Root Path Cost

: 0

Designated Root

: 80

:00:00:20:06:25:ed:80

Designated Root Priority

: 32

768

Root Bridge Forward Delay

: 15

Root Bridge Hello Time

: 2

Root Bridge Max Age

: 20

RSTP CONFIGURATION
-----------------
Rapid STP/STP Enabled(Global) : NO

Magnum6K25(stp)##

show stp ports

STP Port Configuration
--------------------------------

-------------------- ------------------------------------------------------------------

Port#
