There are two different ways to set up your HP All-in-One with your computer based
on the number of phone ports on your computer. Before you begin, check your
computer to see if it has one or two phone ports:
●
If your computer has only one phone port, see the next section, Set up your
HP All-in-One to a computer with one phone port . You will need to purchase a
parallel splitter (also called a coupler), as shown below. (A parallel splitter has
one RJ-11 port on the front and two RJ-11 ports on the back. Do not use a 2-line
phone splitter, a serial splitter, or a parallel splitter which has two RJ-11 ports on
the front and a plug on the back.)
Example of a parallel splitter
● If your computer has two phone ports, see Set up your HP All-in-One to a
computer with two phone ports .
Set up your HP All-in-One to a computer with one phone port
This section describes how to set up your HP All-in-One with a computer modem if
your computer has only one phone port.
Back view of the HP All-in-One
1 Telephone wall jack
2 Phone cord connected to the "2-EXT" port
3 Parallel splitter
4 Telephone
5 Computer with modem
6 Phone cord supplied in the box with your HP All-in-One connected to the "1-LINE" port
To set up your HP All-in-One to a computer with one phone port
1.
Find the phone cord that connects from the back of your computer (your
computer modem) to a telephone wall jack. Disconnect the cord from the
