Mailbox Messaging PTQ-PDPMV1 ♦ Quantum Platform
User Manual PROFIBUS DP Master Network Interface Module for Quantum
Page 174 of 306 ProSoft Technology, Inc.
August 12, 2014
6.2.10 Mailbox Message: Start Slave
This mailbox message starts a selection of slaves that was previously removed
from the processing cycle by means of the mailbox message
FB_APPL_STOP_SLAVE.
The message is allowed in all operation modes (STOP, CLEAR and OPERATE).
Note: The message will be accepted even if one or several slaves are not part of the configuration
and can therefore obviously not be started. The application can, however, find out about this
situation by evaluating the "Fault information" and "Message data words" of the response.
Command and Response Layout: Start Slave
Command Response
Message ID (ID) (ID)
Message information 0240h 0200h
Command 0B00h 0B00h Start Slave
Data size 7E00h 7E00h
Frame count 0100h 0100h
Frame number 0100h 0100h
Offset high 0000h 0000h
Offset low 0000h 0000h
Extended word 1
Extended word 2 - -
Extended word 3 - -
Extended word 4 - -
Extended word 5 - -
Extended word 6 - -
Extended word 7 - Additional Fault Information
Extended word 8 - Fault Information
Message data word 1 Slave 1 Slave 0 Slave 1 Slave 0
Message data word 2 Slave 3 Slave 2 Slave 3 Slave 2
Message data word 3 to
62
... ... ... ...
Message data word 63 Slave 125 Slave 124 Slave 125 Slave 124
