284 ArcGlide THC Instruction Manual 806450
B – ArcGlide THC Serial Communication Installation
Plasma board adapter cable (223260)
Connector A
Pin No.
Wire
color
Signal
Connector B
Pin No.
6
7 White
Black
Motion +
Input common -
28
9
18
19 White
Brown
Pierce output A
Pierce output B
13
32
20
21 White
Red
Hold output A
Hold output B
14
33
22
23 White
Orange
Start output A
Start output B
15
34
28
31 White
Yellow
Field common
Plasma 24 V field
18
37
34
35 White
Green
1/50 Arc Voltage +
1/50 Arc Voltage -
35
16
Connects the plasma cable to J5 on the plasma board.
Length = 520.70 mm (20.50 inch)
Diameter = 12.70 mm (0.50 inch)
Bend radius = 152.40 mm (6.00 inch)
Connector A Connector B
1
18
1
50
33
37
19
20
17
34
