Comtech EF Data HPCST-5000 - Manual (Page 63)

High-Power TWTA Satellite Terminals Single Thread System Installation
Rev.1 2–17
R F O U T
A IR E X H A U S T A IR IN L E T
P O W E R
M O N ITO R
A N D C O N T R O L
R F IN P U T
(T Y P E N )
R F S A M P L E
(T Y P E N )
M O U N T IN G H O L E S M O U N T IN G H O LE S
Figure Chapter 2-3. 300W and 350W TWTA External Connections
