1.3 Equipment List
Refer to Table 1-6 through Table 1-10 for an equipment list for single thread and
redundant systems.
Notes:
1. These lists are subject to change without notice.
2. Indented part numbers are subsets of higher level part numbers, and are shown
for reference only.
Table 1-6. HPCST-5000/-7000 Single Thread Systems Equipment List (Typical)
Description EFData Part Number Notes
Single CST-5000 System:
RFT-500 (No TWTA)
RFT-700 (No TWTA)
Std Cable, AC
Std Cable, DC
Univ Mounting Kit
.CST500....../.CST700.......
.RFT500/.......
.RFT700/.......
KT/3272-1
KT/3272-2
KT/3576 option
option
option
option
Single C-band LNA System
LNA Assy, EFD Std CST
.CA.......
Single HPCST-5000/7000 System
Single HPCST-5000 System
Single System Cable Harness
Waveguide ABS 1:2 Ku-band
HPA-500/700 TWT Amplifier
C-Band HPA TWTA 140W
C-Band HPA TWTA 350W
Mounting Kit, HPA (C/KST)
HPC-1200
.HPCST500..../.HPCST700.....
PL/5129
CA/5124
KT/5115
.HPA500..../.HPA700.....
RF/XT-100C
RF/XT-400C
KT/5032
RF/XTC-100
option
option
option
