High-Power TWTA Satellite Terminals Single Thread System Installation
Rev.1 2–3
2.2 Inspecting the Equipment
1. Carefully check the equipment for damage incurred during shipment.
2. Carefully check the equipment against the packing list shipped with the
equipment to ensure that the shipment is complete. Refer to the following
paragraphs.
2.2.1 Included Parts
A typical single thread TWTA configuration contains the following components.
Notes:
1. Parts are not drawn to scale.
2. Because each system can be custom ordered, it is beyond the scope of this
manual to provide the unlimited configuration possibilities.
Qty. Description Qty. Description
1 TWT amplifier. 1 High-power TWTA Satellite Terminals
Installation and Operation Manual.
1 Envelope containing the test data.
Notes:
1. C-Band TWTAs (HPA-500/-700) utilize waveguide kit KT/5115.
2. The Ku-Band TWTA (HPA-1200) utilizes waveguide kit KT/2820.
