1.4.6 Physical Size and Weight
The physical size and weight of the system components are listed in Table 1-20.
Table 1-20. Physical Size and Weight Characteristics
Component Maximum Size and Weight, Inches Maximum Size and Weight, Metrics
RFT-500, -700,
-1200:
Single Thread
Redundant 23” L x 9.3” W x 10.3” H, 40 lb. max.
Not Specified 58.42 x 23.6 x 26.16 cm; 18.1 kg
HPA-500, -700:
Single Thread:
140W
350W
Redundant:
140W
350W
16” L x 8.6” W x 9” H, 45 lb.
21” L x 10.3” W x 11” H, 55 lb.
(includes W/G components and switch)
32” L x 32” W x 12” H, 95 lb.
32” L x 36” W x 15” H, 160 lb.
40.63 x 21.84 x 22.86 cm; 20.41 kg
53.34 x 26.16 x 27.94 cm; 24.95 kg
81.28 x 81.28 x 30.48 cm; 43.1 kg
81.28 x 91.44 x 38.1 cm; 72.57 kg
HPA-1200:
Single Thread:
100W
300W
Redundant:
100W
300W
16” L x 8.6” W x 9” H, 45 lb.
21” L x 10.3” W x 9” H, 55 lb.
32” L x 32” W x 12” H, 95 lb.
32” L x 32” W x 15” H, 150 lb.
40.63 x 21.84 x 22.86 cm; 20.41 kg
53.34 x 26.16 x 22.86 cm; 24.95 kg
81.28 x 81.28 x 30.48 cm; 43.1 kg
81.28 x 91.44 x 38.1 cm; 68.04 kg
HPC-1200 19” L x 18” W x 3.5” H, TBD lb.
(w/brackets) 48.26 x 45.72 x 8.89 cm
HPC-1110 19” L x 6.6” W x 1.6” H, TBD lb.
(w/brackets) 48.26 x 16.76 x 4.064 cm
RSU-503L 8” L x 11” W x 8” H, 7.5 lb. 20.32 x 27.94 x 20.32 cm; 3.40 kg
LNA Assy. (Dual):
C-Band
Ku-Band 26” L x 21” W x 14” H, 20 lb.
12” L x 7.1” W x tbd H, TBD lb. 66.4 x 53.34 x 35.56 cm; 9.072 kg
30.48 x 18.03 cm
