High-Power TWTA Satellite Terminals Introduction
Rev. 1 1-17
1.4 Specifications
1.4.1 System Interface
Table 1-10 lists the types of interface required for each system component.
Table 1-10. System Interfaces for System Components
Description Type
RFT-500, -700:
TX IF Input (J1)
RX IF Output (J3)
RX RF Input (J4, C-band)
TX RF Output (J2, C-band)
M&C Control (J6) TNC female , 50
Ω
, VSWR 1.25:1 max.
TNC female , 50
Ω
, VSWR 1.25:1 max.
N, female, VSWR 1.25:1 max.
N, female, VSWR 1.25:1 max.
Circular, PT06E-16-26S
RFT-1200:
TX IF Input (J1)
RX IF Output (J3)
RX RF Input (J4, Ku-band)
TX RF Output (J2, Ku-band)
M&C Control (J6) TNC female, 50
Ω
, VSWR 1.25:1 max
TNC female, 50
Ω
, VSWR 1.25:1 max
N, female, VSWR 1.25:1 max
N, female, VSWR 1.25:1 max
Circular type, PT06E-16-26S
HPA-500, -700:
RF TX Output (W/G Port)
RF RX Input (J3, C-band)
RF TX Sample (J4, C-band)
M&C Control (J2)
CPR-137G, VSWR:
2.2:1 max. (for 140W), or 1.3:1 (for 350W)
N, female, VSWR: 1.3:1
N, female, VSWR: 1.3:1; typical 42 dB coupler
Circular, PT06E-18-32S
HPA-1200:
RF TX Output (W/G Port)
RF RX Input (J3, Ku band)
RF TX Sample (J4, Ku-band)
M&C Control (J2)
WR-75 G, VSWR:
2.2:1 max. (for 100W) or 1.3:1 (for 300W)
N, female, VSWR: 1.3:1
N, female, VSWR: 1.3:1; typical 42 dB coupler
Circular type, PT06E-18-32S
Redundant TWTA Assembly
Customer Interface (P1)
Circular type, PTO6E-20-41S
LNA Assy.:
RF RX Input (W/G)
RF RX Output (2x)
Block Converter Output
1:1 Switch Control
CPR-229G, VSWR 1.25:1 max. (C-band)
WR-75 G, VSWR 1.25:1 max (Ku-band)
N, VSWR 1.25:1 max., female
N, VSWR 1.3:1 max., female
Circular, PT06E-14-19P
HPC-1110:
ODU #1 M&C (J1)
ODU #2 M&C (J2)
Remote M&C (J3)
W/G Switch #1
External Interlock D-type, 37 pin, female
D-type, 37 pin, female
D-type, 9 pin, female
D-type, 15 pin, male
D-type, 15 pin, male
1:1 TWTA W/G Switch Control Circular, MS3116E-14-12P
