Programming Guide for Redundant Controller
High-Power TWTA Satellite Terminals
A–12
Rev. 1
2
RF Power Query (forward). Requires a diode detector connected to the auxiliary RF sample port “A”.
Input: No data or 1 byte of data.
Returns power on sample port “A”
Returns power on C/X channel
Returns power on Ku channel
Returned: Power returned in XX.X dBm.
L
RF Power Query (load). Requires a diode detector connected to auxiliary RF sample port “C”.
Input: No data or 1 byte of data.
Returns power on sample port “C”
Returns power on C/X channel
Returns power on Ku channel
Returned: Power returned in XX.X dBm.
R
RF Power Query (reflected). Requires a diode detector connected to auxiliary RF sample port “B”.
Input: No data or 1 byte of data.
Returns power on sample port “B”
Returns power on CX channel
Returns power on Ku channel
Returned: Power returned in XX.X dBm.
