Introduction High-Power TWTA Satellite Terminals
Rev. 1 1-18
Table 1-10. System Interfaces for System Components (Continued)
Description Type
RSU-503L:
M&C for RFT #A (J4)
IF RX Input (J2)
IF TX Output (J1)
M&C for RFT #B (J8)
IF RX Input (J6)
IF TX Output (J5)
Remote M&C (J16)
IF RX Output (J15)
IF TX Input (J14)
Waveguide Switch (J10) Circular, PT06E-16-26S
TNC, female
TNC, female
Circular, PT06E-16-26S
TNC, female
TNC, female
Circular, PT06E-16-26S
TNC, female
TNC, female
Circular, PT06E-14-19S
1.3.2 Prime Power
Table 1-11 specifies the prime power specifications for each system component.
Table 1-11. Prime Power
Assembly Options Prime Power
RFT-500, -700 (J5) AC 90 to 230 VAC, 47 to 63 Hz, 1.0A
RFT-1200 (J5) AC 90 to 230 VAC, 47 to 63 Hz, 1.0A
HPA-500, -700 (J1):
140W
350W AC
AC
Prime Power/Power Consumption
115 or 230 VAC,
±
20%, 47 to 63 Hz, 950 VA
100 to 230 VAC, 47 to 63 Hz, 1550 VA
HPA-1200 (J1):
100 W
300 W AC
AC
Prime Power/Power Consumption
115 or 230 VAC,
± 20%, 47 to 63 Hz, 950 VA
100 to 230 VAC, 47 to 63 Hz, 1550 VA
HPC-1110 AC 90 to 230 VAC, 47 to 63 Hz
RSU-503L (J4, J8) DC +10.8 VDC from either RFT
LNA DC +10.8 ± 0.2 VDC as provided from RSU
