High-Power TWTA Satellite Terminals Programming Guide for Redundant Controller
Rev. 1 A–11
A.3.1 Controller Query Commands
The controller query commands and responses are listed in Table A-5.
Table A-5. Redundant System Controller Query Commands
ASCII Description
0 ID/Version. Returns a 10 character string identifying the controller model number and software revision.
The first 7 characters define the model number, the 8th character is the software major revision, and the
9th and 10th characters are the software minor revision numbers.
1 Summary Status. Five bytes of status are returned.
Byte Bit Meaning
1
7 Parity
6 Complement of bit 5
5 RF input switch control flag
4 Local (1)/Remote (0)
3 Change Flag
2 RF Inhibited (1)
1 Waveguide Switch 1: Position “A” bit = (1), Position “B” bit = (0)
0 (LSB) Automatic bit = (1)/Manual bit = (0)
2 7 (MSB) Parity
6 Complement of bit 5
5 Waveguide switch fault
4 Input transfer switch fault
3 Reflected power fault
2 TWTA “A” fault bit = (1)
1 TWTA “B” fault bit = (1)
0 TWTA “C” fault bit = (1)
3 7 (MSB) Parity
6 Complement of bit 5
5 CX channel reflected power fault
4 Ku channel reflected power fault
3 Maintenance mode flag (1), (Local/Manual)
2 TWTA “A” RF inhibit flag bit = (1)
1 TWTA “B” RF inhibit flag bit = (1)
0 TWTA “C” RF inhibit flag bit = (1)
4 7 (MSB) Parity
6 Complement of bit 5
5 Hot Standby bit = (1), Cold Standby bit = (0)
4 UPS function enabled bit = (1)
3 Constant power mode bit = (1)
2 Waveguide Switch 2: Position A bit = (1), Position B bit = (0)
1 Waveguide Switch 3: Position A bit = (1), Position B bit = (0)
0 Waveguide Switch 4: Position A bit = (1), Position B bit = (0)
5 7 (MSB) Parity
6 Complement of bit 5
5 Transfer Switch 1: Position A bit = (1), Position B bit = (0)
4 Transfer Switch 2: Position A bit = (1), Position B bit = (0)
3 TBD
2 TBD
1 TBD
0 TBD
