224 9369700990 Rev R
Registers Data Description Access
Data
Format
42608 Defined
42609 Loop gain for var limiter RW FLOAT
42611 Integral gain for var limiter RW FLOAT
42613 to
42675 Reserved for future C8 use Not
Defined
42676 Secondary Stability Range (Gain Table Index) RW FLOAT
42678 Secondary AVR - Proportional Gain Kp RW FLOAT
42680 Secondary AVR - Integral Gain Ki RW FLOAT
42682 Secondary AVR - Derivative Gain Kd RW FLOAT
42684 Secondary AVR - Loop Gain Kg RW FLOAT
42686 Secondary AVR - Derivative Time Constant Td RW FLOAT
42688 to
42999 Reserved for future C8 use R Not
Defined
Holding Registers for Protection Function Parameters
Table 43. Information Category C9—Protection Function Parameters
Registers Data Description Access
Data
Format
43001 Primary Exciter Field Overvoltage RW UINT16
43002 Primary Exciter Field Overcurrent RW UINT16
43003 Primary Generator Undervoltage RW UINT16
43004 Primary Generator Overvoltage RW UINT16
43005 Primary Field Over Temperature RW UINT16
43006 Primary Loss of Field RW UINT16
43007 Primary Loss of Field Isolation Transducer RW UINT16
43008 Primary Power Low RW UINT16
43009 24 Volts/Hz RW UINT16
43010 to
43012 Not used R Not
Defined
43013 Inverse Time Curve Exponent RW UINT16
43014 to
43024 Not used R Not
Defined
43025 Active Protection Setting Group R UINT16
43026 Primary Field Overvoltage Level RW FLOAT
43028 Primary Field Overcurrent Level RW FLOAT
43030 Primary Generator Undervoltage Level RW FLOAT
43032 Primary Generator Overvoltage Level RW FLOAT
43034 Primary Field Overvoltage Time Delay RW FLOAT
43036 Primary Field Overcurrent Time Dial RW FLOAT
43038 Primary Generator Undervoltage Time Delay RW FLOAT
43040 Primary Generator Overvoltage Time Delay RW FLOAT
43042 Primary Field Over Temperature Level RW FLOAT
43044 Primary Field Over Temperature Time Delay RW FLOAT
43046 Primary Loss of Field Level RW FLOAT
43048 Primary Loss of Field Time Delay RW FLOAT
43050 Primary Loss of Field Isolation Transducer Level R FLOAT
43052 Primary Loss of Field Isolation Transducer Time Delay RW FLOAT
43054 Primary Power Low Level R FLOAT
43056 Primary Power Low Time Delay R FLOAT
43058 to
43124 Reserved for future C9 use R Not
Defined
43126 Secondary Exciter Field Overvoltage R UINT16
43127 Secondary Exciter Field Overcurrent R UINT16
Modbus™ Communication DECS-400
