Memory Maps and Registers
MVME2500-ECC Installation and Use (6806800N30F) 88
5.3 Linux Devices Memory Map
The table below lists the memory ranges designated to different devices in Linux.
Table 5-2 Linux Devices Memory Map
Device Memory Range Memory Area Size
Ram Mem 0x00000000 0x7fffffff 2 GB
PCIE3 Mem 0x80000000 0x9fffffff 512 MB
PCIE2 Mem 0xa0000000 0xbfffffff 512 MB
PCIE1 Mem 0xc0000000 0xdfffffff 512 MB
MRAM 0xfff00000 0xfff7ffff 512 KB
PCIE3 IO 0xffc00000 0xffc0fff 64 KB
PCIE2 IO 0xffc10000 0xffc1ffff 64 KB
PCIE1 IO 0xffc20000 0xffc2ffff 64 KB
QUART0 0xffc40000 0xffc4ffff 64 KB
QUART1 0xffc50000 0xffc5ffff 64 KB
QUART2 0xffc60000 0xffc6ffff 64 KB
QUART3 0xffc70000 0xffc7ffff 64 KB
Timer 0xffc80000 0xffc8ffff 64 KB
FPGA 0xffdf0000 0xffdf0fff 4 KB
ecm local access window CCSR 0xffe00000 0xffe00ffff 4 KB
ecm (Error Correction Module) CCSR 0xffe01000 0xffe01fff 4 KB
Memory Controller CCSR 0xffe02000 0xffe02fff 4 KB
I2C1 CCSR 0xffe03000 0xffe030ff 256 B
I2C2 CCSR 0xffe03100 0xffe031ff 256 B
UART0 CCSR 0xffe04500 0xffe045ff 256 B
UART1CCSR 0xffe04600 0xffe046ff 256 B
ELBC CCSR 0xffe05000 0xffe05fff 4 KB
SPI CCSR 0xffe07000 0xffe07fff 4 KB
PCIE3 CCSR 0xffe08000 0xffe08fff 4 KB
