Chapter 2
MVME2500-ECC Installation and Use (6806800N30F) 29
Hardware Preparation and Installation
2.1 Overview
This chapter provides installation and safety instructions for this product. Installation
instructions for the optional PMC and transition module are also included.
A fully implemented MVME2500-ECC consists of the base board plus:
 PCI Mezzanine Card (PMC) or PCI eXpress Mezzanine Card (XMC) for added versatility
 Rear Transition Module (RTM)
 SATA kit
The following are the things that need to be done before using the board. Be sure to read the
entire chapter, including all caution and warning notes, before you begin.
1. Unpack the hardware. Refer to Unpacking and Inspecting the Board on page 30
2. Configure the hardware by setting jumpers on the board and RTM. Refer to Configuring the
Board on page 34
3. Install the transition module in the chassis. Refer to Rear Transition Module on page 35 .
4. Install PMC module (if required). Refer to PMC/XMC Support on page 36 .
5. Install XMC span module (if required). Refer to PMC/XMC Support on page 36 .
6. Install the board in the chassis. Refer to Installing and Removing the Board on page 37 .
7. Attach cables and apply power. Refer to Completing the Installation on page 39 .
