5.5.4
Counter High and Low Word Registers
When enabled, the tick timer counter register increments every microsecond. Software may
read or write the counter at any time.
Table 5-25 Counter High Word Registers
REG
Tick Timer 0 Counter Value High Word - 0xFFC80208
Tick Timer 1 Counter Value High Word - 0xFFC80308
Tick Timer 2 Counter Value High Word - 0xFFC80408
Bit
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Field
TickTimer Counter Value High Word (16-bits)
OPER
R/W
RESET
0x0000
Table 5-26 Counter Low Word Registers
REG
Tick Timer 0 Counter Value Low Word - 0xFFC8020A
Tick Timer 1 Counter Value Low Word - 0xFFC8030A
Tick Timer 2 Counter Value Low Word - 0xFFC8040A
Bit
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Field
TickTimer Counter Value Low Word (16-bits)
OPER
R/W
RESET
0x0000
