Round_trip_delay register, Xcvr_bitslip register, Round_trip_delay register -19 – Altera CPRI v6.0 MegaCore Function User Manual
Page 108: Xcvr_bitslip register -19
Bits
Field Name
Type
Value on
Reset
Description
23
rx_ex_
delay_
valid
RC
1'b0
Indicates that the
rx_ex_delay
field has been updated.
22:
RX_
BUF_
DEPTH
Reserved
UR0
0
(
RX_
BUF_
DEPTH
-
1):0
rx_ex_
delay
RO
0
Rx buffer extended delay measurement result. Unit is
cpri_
clkout
clock periods.
Related Information
•
on page 3-41
•
Extended Delay Measurement Interface
ROUND_TRIP_DELAY Register
Table 5-25: CPRI v6.0 IP Core ROUND_TRIP_DELAY Register at Offset 0x58
Bits
Field Name
Type
Value on
Reset
Description
31:10
Reserved
UR0
22'b0
9:0
round_
trip_
delay
RO
10'b0
Measured round-trip delay from
aux_tx_rfp
to
aux_rx_rfp
.
Unit is
cpri_clkout
clock periods..
XCVR_BITSLIP Register
Table 5-26: CPRI v6.0 IP Core IXCVR_BITSLIP Register at Offset 0x5C
Bits
Field Name
Type
Value on
Reset
Description
31:21
Reserved
UR0
11'b0
UG-01156
2015.02.16
ROUND_TRIP_DELAY Register
5-19
CPRI v6.0 IP Core Registers
Altera Corporation
