Page 75

S10C100 User's Guide - Rev. A01

StorCase Technology, Inc.

Configuration

Exclude All -

Permits NO servers on the network to access the selected

Hosts

partition. If an include/exclude list was already created, this

option can be used to override the list. The existing list is retained

(the user can still display, add, or remove servers from the list).

Exclude Listed -

Allows the user to enter or select the WWNs or names (aliases)

Hosts

of the specific servers denied access to the selected partition.

If changes to LUN zoning have been made, the system will now confirm your request

to change LUN zoning.

Select Yes and press Enter.

Press Esc to return to the LUN zoning screen.

Changing All Partitions to Include All Hosts

This function allows the user to change all partitions to include all hosts from the General LUN

Zoning menu. This allows the user to quickly change the LUN zoning for all partitions at once

to permit all servers to see all partitions, overriding the existing setting for each partition. The

controller, however, will retain all existing include/exclude lists.

Once this option is used, all previous LUN zoning settings for each partition must be changed

back individually (refer to section "Configuring LUN Zoning" for further information).

To change all partitions to include all hosts:

Select Configuration Menu from the System Menu and press Enter.
The Configuration Menu should now display (Figure 38).

Select General LUN Zoning and press Enter.
The General LUN Zoning screen should now display (Figure 39).

Select Include All Hosts and press Enter.
The system will now confirm your request to include all hosts.

Press Esc to return to the General LUN Zoning screen.
