StorCase Technology Fibre-to-SCSI Single RAID User Manual
Page 58
46
Configuration
StorCase Technology, Inc.
S10C100 User's Guide - Rev. A01
From the Array Menu
From the All Partitions Menu
1.
Select Array Menu from the
System Menu and press Enter.
The Select Array screen should now display, along with a
list of existing arrays.
2.
Select the desired array and
press Enter.
The Array Menu screen should now display.
3.
Select Partition Menu and press
Enter.
The Select Partition screen should now display along with a
list of exisiting partitions for the selected array.
4.
Select the partition to be viewed
and press Enter.
The Partition Menu screen should now display.
1.
Select Partitions Menu from the
System Menu and press Enter.
The Select Partition or Free Area screen should now display,
along with a list of existing partitions and free space.
2.
Select the desired partition and
press Enter.
The Partition Menu screen should now display.
3.
Select Partition Menu and press
Enter.
The Select Partition screen should now display along with a
list of exisiting partitions for the selected array.
4.
Select the partition to be viewed
and press Enter.
The Partition Menu screen should now display.
IFS_80
To view the status of a partition:
1.
Display the Partition Menu.
Figure 32: Partition Menu Screen
The Partition Menu should now display (Figure 32).
