S10C100 User's Guide - Rev. A01 StorCase Technology, Inc.
Configuration 61
Configuring LUN Zoning
Once the server aliases are set up, the user can then set up LUN zoning. This is where the
user will determine which servers can access each partition LUN.
LUN zoning is set up by either including or excluding servers on a list for each partition LUN.
The list can include or exclude up to 16 specific servers (or all servers) for each partition LUN.
The zoning information is stored as part of the array's metadata using the WWN for each server.
The array partition's LUN zoning will remain, even if a new controller is installed or if the
partition's LUN changes.
NOTE: Changes to LUN zoning take effect immediately. Access to partitions should be
limited when the partitions are not in use.
To set up LUN Zoning:
1. Display the Partition Menu.
The Partition Menu should now display (Figure 31).
2. Select LUN Zoning and press Enter.
The LUN exclude or include list should now display (Figure 43).
The default setting for each partition is "Include ALL Hosts", meaning all servers can
access all partitions.
From the Array Menu From the All Partitions Menu
1. Select Array Menu from the
System Menu and press Enter.
The Select Array screen should now display, along with a
list of existing arrays.
2. Select the desired array and
press Enter.
The Array Menu screen should now display.
3. Select Partition Menu and press
Enter.
The Select Partition screen should now display along with a
list of exisiting partitions for the selected array.
4. Select the partition to be viewed
and press Enter.
The Partition Menu screen should now display.
1. Select Partitions Menu from the
System Menu and press Enter.
The Select Partition or Free Area screen should now display,
along with a list of existing partitions and free space.
2. Select the desired partition and
press Enter.
The Partition Menu screen should now display.
3. Select Partition Menu and press
Enter.
The Select Partition screen should now display along with a
list of exisiting partitions for the selected array.
4. Select the partition to be viewed
and press Enter.
The Partition Menu screen should now display.
