14 Configuration
StorCase Technology, Inc. S10C100 User's Guide - Rev. A01
To find HyperTerminal in Windows:
1. Click on Start (normally located at the bottom left of the Windows desktop)
2. Go to Programs
3. Go to Accessories
4. Go to HyperTerminal
Set the preferences as follows:
Setting Value
Terminal Emulation
Font
Translations
Columns
VT-100 or ANSI
Terminal
None
80
IFS_46
Table 1: Terminal Program Preferences
Setting Value
IFS_47
Baud Rate
Data Bits
Stop Bits
Parity
Flow Control
Connector
115,200
8
1
None
None
COM1 (typical)
Table 2: Terminal Program Communications Parameters
Set the communications parameters as follows:
