Alarm Threshold

Procedures

IFS_84

VCC Voltage

Warning: 5V -3.5 and +6.5%

Shutdown: 5V -6.5% and +10%

12V Voltage

Warning: 12V -8% and +8%

Shutdown: 12V -10% and +10%

Onboard Temperature

Warning: 0 C - 5 C and

45 C - 50 C

Shutdown: < 0 C

> 50 C

Check the Disk Array Administrator Utility for more details (refer to section

Accessing the Disk Array Administrator Utility).

CPU Temperature

Warning: 0 C - 5 C and

65 C - 70 C

Shutdown: < 0 C

> 70 C

Check the ambient temperature and lower the threshold (if necessary).

Ambient temperature should be less than 45 C.

Check the Disk Array Administrator Utility for more details (refer to section

Accessing the Disk Array Administrator Utility).

Check the Disk Array Administrator Utility to for more details (refer to section

Accessing the Disk Array Administrator Utility).

Check the Disk Array Administrator Utility for more details (refer to

section Accessing the Disk Array Administrator Utility).

For warning events, allow the controller to continue operation.

For shutdown events, turn OFF power to the controller and send it in for

servicing

Table 7: Alarm Thresholds and Procedures

To enable/disable the alarm:

Select Configuration Menu from the System Menu and press Enter.
The Configuration Menu should now display (Figure 38).

Select Alarm Mute and press Enter.
The Alarm Mute screen will display (Figure 66).
The current setting is marked with an * next to it.
