5.3.4 Pin Definitions of ND-6053
Pin # Signal Name
Description
1
DI10
Digital Input Channel 10
2
DI11
Digital Input Channel 11
3
DI12
Digital Input Channel 12
4
DI13
Digital Input Channel 13
5
DI14
Digital Input Channel 14
6
Default*/DI15 Initial state setting/ Digital Input Channel 15
7
(Y) DATA+
RS-485 series signal, positive
8
(G) DATA-
RS-485 series signal, negative
9
(R) +VS
Power supply, +10V~+30V
10
(B) GND
Ground
11
DI0
Digital Input Channel 0
12
DI1
Digital Input Channel 1
13
DI2
Digital Input Channel 2
14
DI3
Digital Input Channel 3
15
DI4
Digital Input Channel 4
16
DI5
Digital Input Channel 5
17
DI6
Digital Input Channel 6
18
DI7
Digital Input Channel 7
19
DI8
Digital Input Channel 8
20
DI9
Digital Input Channel 9
