Figure 6-1 Data Format Setting of ND-601x
Checksum
0: disable
1: enable
Analog Input Data Format
00: Engineering units
01: % of Full Scale Range
10: Two’s complement of hexadecimal
11: Ohms (6013 only)
Note:
6017/6018 only support engineering units.
6013supports engineering units and ohms
display.
7 6 5 4 3 2 1 0
Reserved
Must to be 0
