2.2 Overview of ND-6510
The ND-6510 is the RS-422/RS-485 signal repeater which is used to extend or
to lengthen the network distance. A NuDAM bus can connect up to 128 modules.
The repeater should be used when the numbers of the modules exceed 128. In
addition, the repeater should also be used when the length of a signal bus is
more than 4000 feet.
2.2.1 Features of ND-6510
z
RS-422/RS-485 signal transceiver & repeater
z
Bi-directions signal transmission for both RS-422/RS-485 ports
z
Automatic transmission direction control
z
Easy setup and installation
z
Maximum 128 modules on a bus
z
Maximum 256 addressable modules
z
High transfer speed
z Surge
protection
z
Lower power consumption
2.2.2 Specifications of ND-6510
Input / Output
♦
Interface : RS-485, differential, 2 half-duplex wires.
RS-422, differential, 4 full-duplex wires
♦
Speed (bps) : 1200, 2400, 4800, 9600, 19.2K, 38.4K, 57.6K, 115.2K
♦
Data Format* :
Data bits : 5 bits, 6 bits, 7 bits, or 8 bits
Stop bits: 1, 2
Parity type: None, Even, Odd
♦
Max RS-485 network bus distance : 4000 feet. (1200 meter)
Note*: It is auto baudrate and parity, data bits adjust.
Bus
