Code
Input Range
Thermocouple
Data
Format
Maximum Minimum
Displayed
Resolution
0E J (0
°C to 760°C) Eng. Units +760.00 +000.00 0.01
°C
0F K (0
°C to 1000°C) Eng. Units +1000.0 +0000.0 0.1
°C
10 T (-100
°Cto400°C) Eng. Units +400.00 -100.00 0.01
°C
11 E (0
°C to 1000°C) Eng. Units +1000.0 +0000.0 0.1
°C
12 R (500
°C to 1750°C) Eng. Units +1750.0 +0500.0 0.1
°C
13 S (500
°C to 1750°C) Eng. Units +1750.0 +0500.0 0.1
°C
14 B (500
°C to 1800°C) Eng. Units +1800.0 +0500.0 0.1
°C
15 N (-270
°C to 1300°C) Eng. Units +1300.0 -0270.0 0.1
°C
16 C (0 °C to 2320°C) Eng. Units +2320.0 +0000.0 0.1 °C
Table 8-3 Thermocouple Type ,Temperature Range and resolution
Code
Output
Range
Data
Format
Maximum
Value
Minimum
Value
Output
Resolutio
n
30 0 to 20 mA Eng. Units 20.000 00.000 4.88
μA
31 4 to 20 mA Eng. Units 20.000 04.000 4.88
μA
32 0 to 10 V Eng. Units 10.000 00.000 2.442 mV
Table 8-4 Analog Output Range and resolution
‹ Example 1:
♦
Input Range is
±5 V
♦
Input is -1.37 Volts
engineering units: -1.3700
‹ Example 2:
♦
Input Range is
±10 V
♦
Input is +3.653 Volts
engineering units: +03.653
‹ Example 3:
♦
Input Range is Type K thermocouple (range 0
°C to 1000°C)
♦
Input is 406.5
°C
engineering units: +0406.5
