218
6.7.23 Set TTL Input Low Trigger Level
@Description
Set the TTL input low trigger level, for voltage level lower than this
value is recognized as logic low.
@Syntax
$(Addr)1L(ThData)
$ Command leading code.
(Addr) Address ID (2-character)
1L TTL input low trigger level command code.
(ThData) The low trigger level for TTL input. The unit is 0.1 V
and its resolution is 0.1 V too. This value range from
0.1 to 5V, which is a 2-digit integer.
@Response
!(Addr)
or
?(Addr)
! Command is valid.
? Command is invalid.
(Addr) Address ID.
@Example
User command: $301L10
Response: !30
Item Meaning Description
$ (Leading Code) Command leading code.
30 (Addr) Address ID is 30H.
1L Set TTL input low trigger level.
10 (ThData) 1 V
(6080)
