143
6.2.2 Read Configuration
@Description
Read the configuration of module on a specified address ID.
@Syntax
$(Addr)2
$ Command leading code
(Addr) Address ID.
2 Command code for reading configuration
@Response
!(Addr)(InputRange/OutputRange/TypeCode)(BaudRate)(
DataFormat/CheckSumFalg/DataFlag)
or
?(Addr)
! Command is invalid.
? Command is invalid.
(Addr) Address ID.
(InputRange) Current setting of analog voltage input,
refers to Table 6-1 for details. 601x
(OutputRange) Current setting of analog voltage output,
refers to Table 6-2 for details. 602x
(TypeCode) It always be 40 (Hex) for digital I/O
modules. 605x,
606x,
6531
Type Code represents the input mode.
(2-character)
50: counter input mode
51: frequency input mode 6080
(BaudRate) Define communication baud rate, refers to Table
6-3 for details. (2-character)
( DataFormat ) Current settings of checksum,
integration time and output data format,
refers to Figure 6-1 for details. 601x
Current settings of checksum,
integration time and output data format,
refers to Figure 6-2 for details. 602x
(CheckSumFlag) Current setting of check-sum flag, refer
to Figure 6-5 for details. (2-character) 605x
Current setting of check-sum flag, refer
to Figure 6-4 for details. (2-character) 6080
(601x,602x,605x,606x,
6080,6531)
