7.4.2 Single Ended Voltage Input
Ground
Signal
Source
AGND
IN(+)
ADC
7.4.3 Current Measurement
Current
Source
R=125 Ohm
%1 accuracy
IN(-)
IN(+)
ADC R
7.4.4 Differential Current Outpu
+IOUT
DAC
-IOUT
Current Loading
