36
2.3.2 Specifications of ND-6530
‹ USB controller:
♦
USB Spec. 1.1 compliant
‹ I/O Interface:
♦
RS-232/422/485 DIP switch selectable
♦
RS-232 support RXD, TXD, RTS, CTS, FGND signals
♦
RS-422 support TX+, TX-, RX+, RX- 4 wires full-duplex signals
♦
RS-485 support DATA+, DATA- signals with auto direction control
♦
Selectable transfer speed with 1200, 2400, 4800, 9600, 19200, 38400,
57600, 115200 bps
♦
2500Vrms isolation
♦
Surge protection on all signal lines
‹ Connector:
♦
USB type B
♦
10 pin screw terminal block
‹ LED Indicator:
♦
ON: Receiving USB power
♦
Flashing: Data transfer
♦
OFF: No power applied
‹ Cable: Type A to type B
‹ Storage Temperature Range: -25 to 80 °C
‹ Operating Temperature Range: -10 to 70 °C
‹ Power Requirement: USB bus power
‹ Power Consumption: 0.795W
‹ Case: ABS with captive mounting hardware
‹ CE Class A Conformity
