268
approximately 0.0153
°C). (For more detail, please refer the
CJC Offset Calibration Command).
11. Repeat procedure 7 to procedure 10 if the CJC value still
does not conform to the ambient temperature.
Analog Input Module‘s Calibration Voltages
Cod
e
Input Range
Offset
Calibration
voltage
Span
Calibration
Voltage
00
±15 mV
0 mV +15 mV
01
±50 mV
0 mV +50 mV
02
±100 mV
0 mV +100 mV
03
±500 mV
0 mV +500 mV
04
±1 V
0 V +1 V
05
±2.5 V
0 V +2.5 V
06
±20 mA
0 mA +20 mA
0E J (0
°C to 760°C)
0 mV +50 mV
0F K (0
°C to 1000°C)
0 mV +55 mV
10 T (-100
°C to 400°C)
0 mV +30 mV
11 E (0
°C to 1000°C)
0 mV +78 mV
12 R (500
°C to 1750°C)
0 mV +25 mV
13 S (500
°C to 1750°C)
0 mV +19.5 mV
14 B (500
°C to 1800°C)
0 mV +15 mV
15 N (-270
°C to 1300°C)
0 mV +55 mV
16 C (0
°C to 2320°C)
0 mV +39 mV
Table 9-1: ND-6018 Calibration voltages
Cod
e
Input Range
Offset
Calibration
voltage
Span
Calibration
Voltage
08
±10 V
0 mV +10 V
09
±5 V
0 mV +5 V
0A
±1 V
0 mV +1 V
0B
±500 mV
0 mV +500 mV
0C
±150 mV
0 mV +150 mV
0D ±20 mA 0 mA +20 mA
Table 9-2: ND-6012/D/ND-6017 Calibration voltages
