2.4.2 Specifications of ND-6531
Transmission Speed (bps): 1,200 ~ 115,200 (RS-422/485 and RS-232
can be set to different baud rate)
Data Format: RS-232 (RS-422/485 is fixed to 1 stop bit, non-parity, 8
data bits format)
♦
Stop bits: 1, 2
♦
Parity type: None, Even, Odd
♦
Data bits: 5, 6, 7, 8
RS-232:
♦
9 pin D-sub female connector
♦
Support RXD, TXD, RTS, CTS signals
RS-422:
♦
Differential 4 full duplex wires
♦
Support TX+, TX-, RX+, RX- signals
♦
Surge protection on signal pins
RS-485:
♦
Differential 2 half duplex wires
♦
Support DATA+, DATA- signals
♦
Surge protection on signal pins
Isolation Voltage: 1000 V
DC
Storage Temperature Range: -25 to 80
°C
Operating Temperature Range: -10 to 70
°C
Power Requirement: +10V to +30V
DC
Unregulated with against power
reversal
♦
Power Consumption: 1.008W
Case: ABS with captive mounting hardware
CE Class A Conformity
