ADLINK ND-6067 User Manual
Page 181
179
(OutData1)
Each bit is mapping to each channel number
(2-character)
* if the port of ND-6058 is in input mode, output data to this port will be ignore
@Response
or
?(Addr)
>
Command is valid
?
Command is invalid.
(Addr) Address
ID.
@Example 1
User command:
#300003
Response:
>
30 Address
ID
00
Set output to all channels
03
03 (00000011), Channel 0 and 1 are set ON other
channels are set to OFF
@Example 2
User command:
#2F1201
Response:
>
2F Address
ID
12
1 : Set output to single channel
2 : Output single channel is channel 2
01
Set single channel to ON
@Example 3
User command:
#30T0303
Response:
>
30 Address
ID
T
Set output to all port
0303
0303 (0000001100000011), Channel 0, 1, 8 and 9 are
set ON other channels are set to OFF
@Example 4
User command:
#2FT010203
Response:
>
2F Address
ID
T
Set output to all port
01
Set channel 0 of port A ON
