Secure Microcontroller User’s Guide
69 of 187
Figure 8-1. Timed Access
This code allows the reset of the watchdog timer:
MOV 0C7H,#0AAh ; 1st TA Value
MOV 0C7H,#055h ; 2nd TA Value 2 Cycles
SETB IP.7 ; Reset Watchdog Timer 1 Cycle
The watchdog timer bit may have been set using ORL IP, #80H, which takes 2 cycles.
This code allows the reset of the watchdog timer using a different approach:
MOV
A, #55h ; Setup Acc for fast write
MOV 0C7H, #0AAh ; 1st TA Value
MOV 0C7H, A ; 2nd TA Value 1 Cycle
MOV A, IP ; Get Current IP 1 Cycle
ORL A, #80H ; Prepare for fast write 1 Cycle
MOV IP, A ; Reset Watchdog Timer 1 Cycle
Note that a new value for IP could have been retrieved from any direct register instead of
the current IP.
Table 8-A lists the bits that are write-access protected by the timed-access function.
Table 8-A. Timed-Access-Protected Control Bits
NAME MICRO LOCATION DESCRIPTION
EWT All Secure Micros PCON.2 Enables the Watchdog Timer Reset function
RWT All Secure Micros IP.7 Resets the Watchdog Timer count
STOP All Secure Micros PCON.1 Stop Mode Enable
POR All Secure Micros PCON.6 Power-on Reset
PAA DS5000 series MCON.1 Partition Address Access bit (protects PA3–0)
PA3–0 DS5001, DS5002 series MCON.7–4 Partition Address Bits
AE DS5001, DS5002 series RPCTL.4 Access Enable
The timed-access feature is especially useful in protecting the watchdog timer control bits during the
interval before the timeout of the watchdog timer. The EWT bit is protected to prevent errant software
from disabling the watchdog timer, and the protection of the RWT bit prevents an accidental restart of the
watchdog timeout. Thus software must really intend to reset the timeout in order to do so.
4 CYCLES
2 CYCLES
WRITE
AAh WRITE
55h WINDOW FOR
TIMED ACCESS CLOSES
