RPS.0: OBF
Output Buffer Full Flag is set following a write of the DBBOUT by the DS5001/2,
and is cleared following a read of the DBBOUT by the external host.
Initialization:
Cleared when RPC=0.
Read Access:
Can be read by the DS5001/2 and host CPU when in RPC mode.
Write Access:
Written automatically as part of the RPC communication. Cannot be set by the
application software
.
12.6 RPC Protocol
Data is written to the microprocessor by the host CPU and is placed in the DBBIN. At this time, the IBF
flag is set in the RPC Status Register. If enabled by the IBI bit in the RPCTL register, an IBI interrupt
will occur. No further updates of the DBBIN will be allowed until the buffer is read by the
microprocessor. Once read, the IBF flag will be cleared. When the DBBOUT is written to by the
microprocessor, the OBF is set in the RPC Status Register (STATUS). No future writes are allowed until
the DBBOUT is read by the external host. The OBF is cleared when such a read takes place.
The RPC mode provides a simple interface to a host processor. In general, four control bits specify the
operation to be performed. This works as shown in
Figure 12-6 .
These conditions provide the basis of a complete slave interface. The protocol for such communications
might operate as follows:
1) Host processor reads STATUS.
2) If DBBIN is empty (IBF = 0), host writes a data or command word to DBBIN.
3) If DBBOUT is full (OBF = 1), host reads a word from DBBOUT.
4) RPC detects IBF flag via interrupt or polling. Input data or command word is processed.
5) RPC recognizes OBF = 0, and writes a new word to DBBOUT.
Timing diagrams in RPC AC electrical specifications illustrate the operation of the RPC mode bus
transfers. A DBBOUT read places the contents of DBBOUT on the data bus and clears OBF. A STATUS
register read places the contents of the STATUS register on the data bus. A write to DBBIN causes the
contents of the data bus to be transferred to the DBBIN, and the IBF flag (STATUS) is set. A command
write operates in the same way. The DS5001FP or DS5002FP can deter-mine whether the write was data
or command by examining the IA0 bit in the STATUS register. This bit will be equal to the A0 input of
the most recent valid host write operation.
12.7 DMA Operation
If DMA transfers are required, the RPC mode can support them. DMA transfers are initiated by setting
the DMA bit in the RPCTL register. The DRQ output is de-asserted at this time. DRQ can be asserted by
writing a 1 to the DRQ line (P2.6) from software. The host CPU must respond by pulling the
DACK input
low. Data can then be transferred according to the user’s required protocol. DMA mode can be cancelled
by clearing the DMA bit, by a reset, or by clearing the RPCON bit of the RPCTL control register to leave
the RPC mode.
