13. PROGRAMMABLE TIMERS
13.1 Functional Description
The secure microcontroller incorporates two 16-bit timers called Timer 0 and Timer 1. Both can be used
to generate precise time intervals, measure external pulse widths, or count externally applied pulses.
Each programmable timer operates either as a “timer,” in which time periodic interrupts may be generated
or as a “counter,” in which the timer register is incremented when transitions are detected on an external
input pin.
When a programmable timer is operating as a timer, the least-significant timer register is incremented
once every machine cycle or at 1/12 the frequency of the clock oscillator. When a 12MHz crystal is used,
the register will be incremented once every 1µs.
When counter operation is selected, the least-significant timer register is incremented each time that a 1-
to-0 transition is detected on the corresponding input pin that may be assigned for the timer (T0 for Timer
0, T1 for Timer 1). These pins are the optional function of P3.4 and P3.5 respectively. The timing of the
“counter” mode is internally synchronized to the machine cycles. During S5P2 of every machine cycle,
the external input pin is sampled. A 1-to-0 transition is defined as a 1 detected during a machine cycle
followed by a 0 detected in the S5P2 clock phase of the next machine cycle. The new count value in the
timer register will be present during clock phase S3P1 of the next successive (or third) machine cycle. See
the section on timing for details.
The TMOD and TCON SFRs are used to control the initialization of the two programmable timers. A
summary of the bits contained in TMOD is shown in TMOD Register Control Bit Summary. The relevant
TCON register bits are depicted in TCON Register Control/Status Bits. Each Timer has four control bits
associated with it including C/
T , GATE, M1, and M0. C/ T = 1 selects counter operation and C/ T = 0
selects timer operation.
A separate GATE bit in the TMOD register is provided for each timer. These bits enable an associated
external interrupt input pin as a gating control for the timer or counter function. The P3.2 (
INT0 ) pin
operates in conjunction with Timer 0 while the P3.3 ( INT1 ) pin operates with Timer 1. When the Timer
Run bit (TRn) and GATE are both set to 1, the timer or counter function will be enabled only during the
times that the associated interrupt input pin is at a 1 level. When the Timer function is selected, the GATE
bit provides a means of measuring the widths of logic 1 pulses applied to the interrupt pin in units of
machine cycles. When the counter function is selected, the pulse is measured in units of 1-to-0 transitions
detected on the external counter input pin.
Both of the programmable timers have M1, M0 control bits in the TMOD register which are used to
select one of the four operating modes described below.
