EVCO S.p.A. Vcolor 818 | Installer manual ver. 1.1 | Code 144VC818E114
page 91 of 94
Digital outputs:
8 outputs (electromechanical relays):
- 1 x 16 A res. output @ 250 VAC SPST type (K1) for
compressor management
- 6 x 8 A res. outputs @ 250 VAC of which five SPST type for
managing defrosting (K2), the evaporator fan (K3), the
condenser fan (K4), cabinet light or UV light (K7), the pump
down valve or alarm output (K8) and one SPDT type for
management of the door heating elements (K5)
- 1 x 16 A res. output @ 250 VAC SPDT type (K6) for heating
management of the needle probe.
Displays:
16 colours 3.5" touch-screen TFT graphic display and with 320 x
240 pixel resolution.
Type of actions 1 or 2: Type 1.
Type of actions 1 or 2 and
complementary features:
C.
Communication port:
2 ports:
- 1 RS-48 serial port with MODBUS communication protocol
- 1 USB serial port
Alarm and signalling buzzer: incorporated.
