EVCO S.p.A.
Vcolor 818
| Installer manual ver. 1.1 | Code 144VC818E114
page 79 of 94
12.4
Download of the information relative to the HACCP
alarms
To make the download of the information relative to the HACCP alarms operate as follows:
1.
Make sure the device is in the “stand-by” status.
2.
Insert an USB peripheral in the USB serial port.
3.
Press and release the SET key (1), the + key (2) or the - key (3) to set the day and the time from which the
information must begin, then press and release the START / STOP key (4): it will automatically be started the
writing (into the peripheral) of a CSV (Comma Separated Values) document by name (for example)
“log247n00001.csv” (containing information relative to the HACCP alarms); the writing procedure can take
some seconds.
The name of the CSV document is made (with reference to the example) as follows:
-
“log”: fix field
-
“247”: value of paramater LA (device address)
-
“n”: fix field
-
“00001”: progressive number of downloads of the information relative to the HACCP alarms.
To set the kind of information to be downloadedoperate as follows:
3.1
Make sure the device is in the “on” status.
3.2
Make sure the keyboard is not locked and no procedure is in progress.
3.3
Press and release the HOME key (1), press and release the MENU key (2), then press and release
the key (3) to select “HACCP”.
3.4
Press and release the SET key (4), then press and release the key (5) to select “SETUP
RECORDING”.
3.5
Press and release the SET key (4), press and release the key (6) or the key (5) to select the
information, then press and release the + key (7), or the – key (8) to add it (or remove it).
Operate as follows to exit the procedure:
