EVCO S.p.A. Vcolor 818 | Installer manual ver. 1.1 | Code 144VC818E114
page 6 of 94
1.2 Summary table of the main features and the models
available
The following table illustrates the main features of the device.
“ / “ indicates the feature can be set via a configuration parameter.
User interface (open frame) Vcolor 818
128.0 x 94.5 mm (5.039 x 3.720 in; L x H) •
TFT graphic display 3.5 (inch) touch-screen with 16 colors
and 240 x 320 pixel resolution
•
Control module (open frame) Vcolor 818
166.0 x 116.0 mm (6.535 x 4.566 in; L x H) •
Connections Vcolor 818
removable screws terminal board •
Power supply Vcolor 818
115... 230 VAC •
Analogue inputs Vcolor 818
cabinet probe PTC/NTC
needle probe 1 PTC/NTC
needle probe 2 PTC/NTC
needle probe 3 PTC/NTC
evaporator probe PTC/NTC
condenser probe PTC/NTC
Digital inputs (for NO/NC contact) Vcolor 818
door micro switch •
compressor circuit breaker protection •
low pressure •
high pressure •
